    UL Atex LED Explosion proof Fluorescent Light Fixtures for Hazardous Areas & Harsh Environment

    Ask Lasest Price
    Brand Name : CESP
    Model Number : CES-XT60
    Certification : CCC, CE, C-tick, EMC, FCC, LVD, PSE, RoHS, SAA, UL
    Price : $70~181
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 50, 000PCS/Month
    Delivery Time : 3-7 days for usual order.
    • Product Details
    • Company Profile

    UL Atex LED Explosion proof Fluorescent Light Fixtures for Hazardous Areas & Harsh Environment

    Feature

    1. For hazardous area lighting products like LED EXPLOSION PROOF LIGHTS, it is fairly important to choose specialized manufacturer because the security for hazardous area lighting is essential.


    2. CESP is a specilized LED EXPLOSION PROOF LIGHT manufacturer in the passed 8 years, with CE/ROHS/UL/CUL/DLC/SAA/PSE certification, and most important, ATEX and CNEX explosion proof certification.


    3. Now we have UL844(class 1 division 2) explosion proof certification, which means we are the only manufacturer who owns these qualifications at the same time.


    4. By now we have a whole series LED EXPLOSION PROOF LIGHTS (CES-J), including 20W-185W wide power range and various installation brackets, and also customizable product color. can satisfy most of the hazardous area lighting application.



    The Standar of CESP LED Explosion proof Linear Lights

    • CSA 250, UL1598, CSA 137, UL844
    • IEC/EN 60079-0, IEC/EN 60079-1
    • IEC/EN60079-15, IEC/EN60079-31
    • Class 1 Div 1 , Group B,C,D
    • Class 1 Div 2, Group A,B,C,D
    • Class II Div 1, Group E,F,G
    • Class II Div 2, Group E,F,G
    • Class III, Ex d IIC T6
    • Ex nA IIC T6
    • Ex tb IIIC T6

    Feature

    Patent design combiningoutstandingappearance and excellentheat dissipation

    High heat transmit heavy duty copper free housing ADC 12 aluminum

    High LED Efficacy: 120 Lm/w

    Universal Voltage: AC100-277V, AC200-480V (50/60Hz)

    Wide ambient temp range from - 40°C to + 55 °C

    Taiwan Meanwell series , UL certified

    Sur-face treatment-power painted, salt resistant

    Shock and vibration resistant tempered glass, super clear 95% light transmit rate


    Parameter

    ItemCES-XT60CES-XT120(D)
    Rated Power60W120W
    Input VoltageAC100-277V, AC200-480V
    Input Frequency50/60Hz
    Power Factor>0.95
    Surge Protection4KV
    Lumen120lm/per watt
    Beam Angle8°/15°/36°/60°/90°/120°

    CCT


    5500K-6000K
    CRI>70
    Operating Temperature-40℃~55℃
    T-CodeT4-T6
    Housing Materialheavy duty copper free ADC12 aluminum alloy
    Tempered glass6mm thickness
    Mounting Opitional

    U-Bracket (Wall, Ceiling and Floor)

    Stanchion Mount

    Pole Mount

    Pendant Mount

    IP RateIP66
    IK RateIK10
    Warranty5 years
    Size596*126*57mm1192*126*112mm
    Weight8kg13kg

    ItemCES-XT30CES-XT60A(D)
    Rated Power30W60W
    Input VoltageAC100-277V, AC200-480V
    Input Frequency
